Item | Unit | Amount | ||
Max. Lifting Capacity | t | 25 | ||
Boom Length | m | 10.2-30 | ||
Jib Length | m | 6.5 | ||
Max. Length of Boom + Jib | m | 30+6.5 | ||
Crane Boom Angle Range | ° | -2~80 | ||
WorkingSpeed | Steel Rope Speed | Hoisting | m/min | 99 |
Dropping | m/min | 99 | ||
Slewing Speed | r/min | 0~1.8 | ||
Travel Speed | Km/h | 0~3.9 | ||
Main Hoist Multiple | t | 4(single rope) | ||
Gradeability | % | 40 | ||
Engine Rating Output Power/ Rotate Speed | Kw/rpm | 137/2200 | ||
Overall Weight | t | 37 | ||
Counterweight | t | 10 | ||
Overall Dimensions | mm | 12955X4200X3000 | ||
Ground Pressure | Kg/cm2 | 0.7 |
