Max. Rated Lifting Weight (t) | 100 | |||
Luffing Range at Max. Rated Lifting Weight (m) | 2.5 | |||
Hoisting Ratio at Rated Load | 14 | |||
Max. Speed of Single Steel Rope for Boom | 135 | |||
Max. Speed of Single Steel Rope for Jib | 135 | |||
Telescoping Time (rising/falling) (s) | 130/120 | |||
Luffing Time(extending/contracting) (s) | 65/70 | |||
Overall Dimension | Length(m) | 15.2 | ||
Width(m) | 4.2 | |||
Height(m) | 3.42 | |||
Slewing Speed (r/min) | 1.85 | |||
Ground Contacting Length of Track Shoes × Rail Gauge (mm×mm) | 5440×4170 | |||
Grade Ability | 40% | |||
Transmission Form | Hydraulic transmission | |||
Traveling Speed(km/h) | 0.8/1.85 | |||
Total Weight (counterweight included) (t) | 117 | |||
Booms & Jib | Boom | Basic boom (m) | 12.8 | |
Total length of booms and Jib (m) | 48 | |||
Jib | Basic Jib (m) | 10 | ||
Installing Angle of Jib (°) | 0, 20 | |||
Jib Hoisting Ratio | 1 |
